Detector Sensitivity Settings $SSHQGL[ & $:$&6 $SSOLFDWLR QV
AFP-300/AFP-400 Programming PN 50259:C1 06/19/97 39
'HWHFWRU6HQVLWLYLW\6HWWLQJV
6HOHFWLQJ 3UH$ODUP DQG
$ODUP 6HQVLWLYLW\
Each detector provides a host of selectable intelligent options. You can program
Pre-Alarm and Alarm detector sensitivity levels (Table 38) in the widest allowed ranges
(0.03 to 4% per foot obscuration). The AFP-300/AFP-400 provides nine levels of
Pre-Alarm (PA:1–PA:9) and Alarm (AL:1–AL:9) in percent per foot obscuration:
•
3$
a self-optimizing setting where the control panel selects a suitable Pre-Alarm
level for a detector.
•
3$²3$
selects the detector Pre-Alarm sensitivity level—with PA:2 the most
sensitive and PA:9 the least sensitive. (PA:0 = no Pre-Alarm).
•
$/²$/
selects the detector Alarm sensitivity level—with AL:1 the most
sensitive and AL:9 the least sensitive.
Table 38 Detector Sensitivity (in percent per foot obscuration)
Detector Type Detector Sensitivity in % per foot obscuration
Alarm
Pre-Alarm
Photo Electric
SMOKE (PHOTO)
SDX-551/SDX-751
(See note 3)
AL:1=0.50 %
AL:2=0.73 %
AL:3=0.96 %
AL:4=1.19 %
AL:5=1.43 %
AL:6=1.66 %
AL:7=1.89 %
AL:8=2.12 %*
AL:9=2.35 %
PA:1=Auto
PA:2=0.30 %
PA:3=0.47 %
PA:4=0.64 %
PA:5=0.81 %
PA:6=0.99 %
PA:7=1.16 %
PA:8=1.33 %*
PA:9=1.50 %
Ion
SMOKE (ION)
CPX-551/CPX-751
(See note 3)
AL:1=0.50 %
AL:2=0.75 %
AL:3=1.00 %
AL:4=1.25 %
AL:5=1.50 %
AL:6=1.75 %*
AL:7=2.00 %
AL:8=2.25 %
AL:9=2.50 %
PA:1=Auto
PA:2=0.40 %
PA:3=0.50 %
PA:4=0.75 %
PA:5=1.00 %
PA:6=1.25 %*
PA:7=1.50 %
PA:8=1.75 %
PA:9=2.00 %
Laser
SMOKE (LPX)
LPX-751
AL:1=0.03 %
AL:2=0.05 %
AL:3=0.10 %
AL:4=0.20 %
AL:5=0.30 %
AL:6=0.50 %*
AL:7=0.70 %
AL:8=0.80 %
AL:9=1.00 %
PA:1=Auto
PA:2=0.02 %
PA:3=0.03 %
PA:4=0.05 %
PA:5=0.10 %
PA:6=0.20 %*
PA:7=0.30 %
PA:8=0.40 %
PA:9=0.50 %
Multi Sensor
MUTLISENSOR
IPX-751
AL:1=0.71 %
AL:2=0.71 %
AL:3=1.00 %
AL:4=1.00 %
AL:5=2.00 %*
AL:6=3.00 %
AL:7=3.00 %
AL:8=4.00 %
AL:9=4.00 %
PA:1=0.71%
PA:2=0.71 %
PA:3=0.50 %
PA:4=1.00 %
PA:5=1.00 %*
PA:6=2.00 %
PA:7=2.00 %
PA:8=3.00 %
PA:9=3.00 %
Notes:
1. * Signifies the factory default setting.
2. The use of alarm sensitivities below 0.50%/ft obscuration requires a 90 day test to ensure that the
environment for the detectors is suitable for the higher sensitivity setting. (Refer to “Testing Detectors Set
Below 0.50%” on page 40.)
3. Suitable for open area protection only with 0 to 300 feet per minute air velocity.
