$SSHQGL[ $ 5HOHDVLQJ $SSOLFDWLRQV
Programming a Releasing Zone
30 AFP-300/AFP-400 Programming PN 50259:C1 06/19/97
,QLWLDWLQJ 'HYLFHV
Releasing zone initiating devices include the following:
• FDX intelligent heat detectors;
• SDX, CPX, LPX, or IPX intelligent smoke detectors; or
• Conventional detection devices listed for the purpose and connected to MMX
modules.
You can use multiple zone initiating devices for the same releasing hazard. Do so by
mapping zone initiating devices to the same releasing zone. Factory Mutual and certain
Local Authorities Having Jurisdiction require using redundant wiring (NFPA 72 Style 6
or Style D) for initiating devices in releasing applications.
:DUQLQJ 6RXQGHUV
Warning sounders connect to any of the four panel Notification Appliance Circuits or to
CMX module circuits (refer to the AFP-300/AFP-400 Installation Manual). The same
releasing hazard can activate multiple Notification Appliance Circuits.
Table 31 Warning Sounder
$X[LOLDU\ &RQWURO
)XQFWLRQV
Table 32 contains instructions for using control functions:
Table 32 Using Control Functions
$&6 $QQXQFLDWLRQ
Table 33 contains instructions for annunciating ACS points and detectors:
Table 33 Annunciating ACS Points and Detectors
To activate a sounder... Do this....
When the delay timer starts, when the
releasing device activates, or both.
Map the CMX module to a releasing hazard zone
(R0-R9).
Immediately when one of the
initiating devices activate.
Map the CMX to a separate zone (not R0-R9) that is
also mapped to all initiating devices of the hazard.
If... Do this...
A releasing application
requires control relays
Use CMX modules set for dry contact operation. Program the
control relays for different functions by following the
instructions in Table 31.
Providing control functions Use an ACM-8R remote relay module mapped to the software
zones of the control panel.
To Annunciate... Do this...
Points of releasing functions Select Annunciator Selection Group 1 or 2 to annunciate any
of the software zones described above, including zones R0-
R9. For instructions, refer to "Annunciator Options" on page
19.
Individual detectors Select Annunciator Selection Group 6, 7, or 8. For
instructions, refer to "Annunciator Options" on page 19.
,I VHOHFWLQJ FURVV]RQLQJ
WKLV VRXQGHU RQO\ DFWLYDWHV
ZKHQ WZR ]RQHV JR LQWR
DODUP
8QOLNH UHOHDVH VROHQRLGV
VRXQGHUV GR QRW ZDLW IRU
WKH GHOD\ WLPHU
,I FRGHG VRXQGV DUH
UHTXLUHG IRU ZDUQLQJ
VRXQGHUV WKH\ PXVW XVH
RQH RI WKH IRXU SDQHO
1RWLILFDWLRQ $SSOLDQFH
&LUFXLWV QRW D &0; FLUFXLW
