Programming 15088:J 10/22/99
4=DACT - UDACT Installation D }X1X8X4X
This option allows the installer to program a Notifier UDACT (Universal Digital Alarm Communicator
Transmitter) and specify its base annunciator protocol address in the system. The example below illustrates
programming a UDACT.
Before programming a UDACT into an AM2020/AFP1010 system, the number of annunciator addresses
required must be determined. First, take the number of annunciator points in the system and add 8 points (for
the UDACT). Then, divide the total by 64 to obtain the number of annunciator addresses required (round up to
next whole number if decimal).
PRESS 1=INSTL,2=ANN,3=XINT,4=DACT :@4
DO YOU WANT TO CHANGE THE UDACT PROGRAMMING?@(Y=YES,N=NO) :@Y
DO YOU WANT A UDACT INSTALLED? (Y=YES,N=NO) :@Y
ENTER THE BASE ADDRESS FOR UDACT OPERATION (1@-@32) :@1
NOTES
• The UDACT can only be programmed into or removed from the system through the Partial System
Programming Menu.
• The UDACT must be programmed at an installed annunciator address. Once programmed, the first 8
annunciator protocol points (base address only) automatically become unique fire panel status
indicators (see UDACT Manual). These 8 functions required by the UDACT override any previous
AM2020/AFP1010 annunciator point programming. When a UDACT is installed, the first 8 AM2020/
AFP1010 annunciator points associated with the UDACT base address cannot be reprogrammed/
removed and have no read status functionality.
• Answering "NO" for the question, "Do you want a UDACT installed?" disables the automatic 8 point
UDACT programming and restores these points to their original annunciator point programming.
• Multiple annunciator addresses may need to be programmed depending upon the range specified by
the UDACT annunciator address switches.
• The UDACT cannot be used in systems containing an AVPS-24/AVPS-24E, AA-30/AA-30E, AA-120,
AA-120E or XP Transponder since a primary power failure signal transmission will not be delayed as
required for this application.
• When using the UDACT in a system with a NIB-96, use care to ensure that the EIA-485 addresses
selected do not overlap with those of the NIB-96.
• When a UDACT is programmed into the system, both the red and yellow LEDs will illuminate on an
annunciator point mapped to a supervisory input during the presence of a supervisory signal for that
point, unless the supervisory ACS reporting option has been enabled.
• Off-premises transmission of security alarms using the UDACT must be made by mapping input
points with the Software Type ID SACM and SEQM to annunciator points within the range of the UDACT.
Use of other security Type IDs for this purpose will result in simultaneous transmission of a trouble
signal.
• Multiple UDACT usage per AM2020/AFP1010 system is not permitted.
