Notifier AFP1010 User Manual

4-26
Security 15088:J 10/22/99
Warning: Observe proper polarity
or device will be damaged.
The CMX control module for ringback is illustrated in Figure 1.3-11.
Figure 1.3-11 CMX Control Module for Ringback
= CM
PPU Signaling Line Circuit Out
PPU Signaling Line Circuit In
CMX-1
or
CMX-2
Note: Tabs on CMX must be broken
when used as a Form-C relay.
Listed 24 VDC
Power Supply
RA400Z
+
-
Figure 1.3-12 Installing an STS-1 Security Tamper Switch
An STS-1 Security Tamper Switch installation is illustrated in Figure 1.3-12 through 1.3-14.
