Notifier LCD-80 User Manual

44 PN 15037:D2 9/9/02
EIA-485
Connections
on LCD-80
CCM-1
(AM2020/
AFP1010) AFP-200
DIA
(AM2020/
AFP1010) NFS-640
AFP-300,
AFP-400,
AFC-600
OUT(-) P3-4 TB5-2 TB1-4 TB12 TB3-4
RET (-) P3-3 TB5-4 TB1-3 TB12 TB3-2
OUT(+) P3-2 TB5-1 TB1-2 TB12 TB3-3
RET (+) P3-1 TB5-3 TB1-1 TB12 TB3-1
Table 3-1 EIA-485 Control Panel Connections (Terminal Mode)
