Notifier LCD-80 User Manual

PN 15037:D2 9/9/02 43
.
Figure 3-2 Terminal Mode EIA-485 Connection
R-120 resistors are required
across In and Out cir
c
uits on
each LCD-80.
See no
tes in the preceding
text.
Re
fer to Appendix A for shield
termination instructions.
Last LCD-80
(must set DIP Switch
SW3-1 and SW3-2
“ON”)
First LCD-80
(set DIP Switch
SW3-1 and SW3-2
“Off” on all LCD-80s
except last one)
P2
P2
Twisted-
Shielded Pairs
EIA-485
Return
EIA-485
Out (-)
Return (-)
Out (+)
Return (+)
EIA-485
Out
Cabinet
*See notes in preceding text.
4
3
2
1
4
3
2
1
