NFS2-3030/E Installation Manual — P/N 52544:N1 07/18/2014 19
Section 3: Installation
3.1 Preparing for Installation
Choose a location for the fire alarm system that is clean, dry, and vibration-free with moderate
temperature. The area should be readily accessible with sufficient room to easily install and
maintain it. There should be sufficient space for cabinet door(s) to open completely.
Carefully unpack the system and inspect for shipping damage. Count the number of conductors
needed for all devices and find the appropriate knockouts. (Refer to Section 3.11 “UL Power-
limited Wiring Requirements” for selection guidelines.)
Before installing the fire alarm system, read the following:
• Review the installation precautions at the front of this manual.
• Installers should be familiar with the standards and codes specified in Section 1.1 “Standards
and Other Documents”.
• All wiring must comply with the National and Local codes for fire alarm systems.
• Do not draw wiring into the bottom 9 inches (22.86 cm) of the cabinet except when using a
separate battery cabinet; this space is for internal battery installation.
• Review installation instructions in Section 3.2 “Installation Checklist”.
3.2 Installation Checklist
The checklist that follows contains references to information included in other manuals; see
Section 1.3 “Related Documents” for document part numbers.
!
WARNING: RISK OF IRREPARABLE EQUIPMENT DAMAGE
MAKE SURE TO INSTALL SYSTEM COMPONENTS IN THE SEQUENCE LISTED BELOW.
FAILURE TO DO SO CAN DAMAGE THE CONTROL PANEL AND OTHER SYSTEM
COMPONENTS.
!
WARNING: RISK OF IRREPARABLE EQUIPMENT DAMAGE
WEAR A STATIC DISCHARGE STRAP ON WRIST TO PREVENT EQUIPMENT DAMAGE.
Task Refer to:
1. Mount the cabinet backbox to the wall. Section 3.3 “Mounting a Cabinet”
2. Attach CPU to chassis Section 3.5 “Attaching the CPU & Chassis”
3. Attach option boards (e.g. SLC loop
modules, network communications
modules, and other devices of the same
size) to chassis.
• Section 3.6 “Attaching Option Boards”
• Section 3.7 “Connecting the Network Communications
Module”
• Installation document for the specific device
4. Attach chassis to backbox as
appropriate for system design
Section 3.4 “Laying Out Equipment in Cabinet and Chassis”
5. Wire relays Section 3.9 “Form-C Relays on the CPU”
6. Attach & wire other system components
 Audio/Voice equipment DVC Digital Voice Command Manual, DAA Digital Audio
Amplifiers Manual, DVC-RPU Manual, AA-series Audio
Amplifiers Manual, DS-DB Manual
 Annunciators and other ACS devices Installation document for the specific device (such as ACS
Manual, ACM-8R Manual, etc.)
Table 3.1 Installation Checklist (1 of 2)
