40 NFS2-3030/E Installation Manual — P/N 52544:N1 07/18/2014
Installation Installing Printers
3.14.2 Configuring the Printer
Refer to the documentation supplied with your printer for instructions on configuring your printer.
PRN Printer Settings
Set the printer options (under the menu area) according to the settings listed in Table 3.3.
Keltron Printer VS4095/5 Settings
The printer communicates using the
following protocol:
• Baud Rate
– Supervised mode: 2400
– Unsupervised mode: 300
(Supervision is a programmed
setting; refer to the Panel
Programming section of the
Programming Manual for
instructions.)
• Data bits: 8
• Parity: None
• Stop bits: 1
Set the printer DIP switches SP1
and SP2 according to settings in
Table 3.4.
*Protocol: When printing in graphics mode, set I/O Serial Protocol to “Robust XON/OFF”.
Option Setting
L/R Adjust 0
Font HS Draft
CPI 10 CPI
LPI 6 LPI
Skip 0.0
ESC Character ESC
Emulate FX-850
Bidirectional Copy ON
I/O
Interface
Buffer
Serial
Baud
Format
Protocol *
Serial
40K
9600
8 Bit, None, 1 Stop
ENQ/STX
CG-TAB Graphic
Character Set Standard
Country E-USA ASCII
Select Zero ON
Auto-CR OFF
Auto-LF OFF
Option Setting
Menu Lock ON
Language English
Paper
Single
Form Adjust
Trac 1
Form Adjust
Trac 2
Form Adjust
Auto Sheet Feeder
Form Adjust
12/72
12/72
12/72
12/72
Auto Tear OFF
F-Eject OFF
Form Length
Trac 1
Lines
Standard
Trac 2
Lines
Standard
66
10.5”
66
10.5”
Barcode Off
Barmode Unsecured
Table 3.3 PRN Setup Options
Supervised Unsupervised
Supervised and
Unsupervised
SP1 On Off SP1 On Off SP2 On Off
1X1X1X
2X 2 X2 X
3X3X3X
4X4X4X
5X 5X 5X
6X6X6X
7X 7X 7X
8X 8X 8X
Table 3.4 Keltron DIP Switch Settings
