Releasing Zones How Releasing Zones Operate
.
Cross Zone Selection
(Cross=)
Condition(s) Required to Activate the Releasing zone
Cross=NONE An alarm from any detector or module activates the releasing circuit.
Cross=YES An alarm from any two detectors or modules activates the releasing
circuit.
Cross=ZONE
An alarm from two detectors or modules mapped to different Software
Zones, but mapped to the same Releasing Zone.
• An alarm from L02D101 and L02D103 – detectors mapped to different
zones, but both list ZR01 in their zone map.
• An alarm from L02D102 and L02D104 – detectors mapped to different
zones, but both list ZR01 in their zone map.
• An alarm from L02D101 and L02D104 – detectors mapped to different
zones, but both list ZR01 in their zone map.
• An alarm from L02D102 and L02D103 – detectors mapped to different
zones, but both list ZR01 in their zone map.
Cross=HEAT
Activation of heat detector L02D104 and one smoke detector (L02D101,
L02D102, or L02D103).
Table B.2 Example of Cross Zone Selections

Notifier NFS2-3030 Specifications

General

Type	Intelligent Fire Alarm Control Panel
Power Supply (6 amps total system power)	6 amps total system power
SLC Loop Voltage	24V DC
NAC Voltage	24V DC
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes, via NOTI-FIRE-NET
Programming	Via VeriFire Tools
Power Supply	120V or 240V AC, 50/60 Hz
Battery Backup	Yes
Communication Ports	RS-232, USB
SLC Loops	1 or 2
NAC Outputs	4
Operating Voltage	24V DC nominal
Number of Signaling Line Circuits (SLC)	2
SLC Loop Current	0.5 A max per loop
Number of Notification Appliance Circuits (NAC)	4
Total NAC Current	6 amps
Number of Relays	4
Relay Contact Rating	2.0 A @ 30 VDC
