MIDI Controlling
Selecting/Using a Template
W
hen MIDI Controlling mode is initially accessed by pressing the PLAY button, the Xio is in
TEMPLATE SELECT mode. The display shows the Template’s name and location in this mode, for example:
When a knob/button is rotated/pressed, the changing value of MIDI data assigned to it is displayed
temporarily. For example, if Filter Frequency is assigned to the Knob 1 on Continuous Controller number
105 and that knob is rotated then the following will be briefly shown:
(065 will not be a fixed value but will change as the knob is rotated.) Once the value has been set and
the knob/button has been released, the currently selected Template reappears after an amount of time
set within the GLOBAL menu. See the GLOBAL Menu section for details.
XIO TEMPLATE:5
FM7
Filter Frequency
065 CC105
