Template Individual Edit ‘Note On/Off’ Menu
Page 1 is the same for all Template Edit Menus (Control Type – see CC Menu for details).
Page Number Page Name DATA Encoder selects…
2 Note Value MIDI note value
3 Button type Action of button
4 Note Velocity Note velocity
5 MIDI Channel MIDI Channel for this control
6 MIDI Ports Port routing for the control
7 Control Naming Name of Control
Here is a detailed breakdown of each page of the individual Template Edit Menu once ‘Note On/Off’ has been
selected on Page 1. Note that Note On/Off can only be selected for buttons:
Edit Menu Page 2 – Actual Note Selection
This page selects any MIDI note to be played when the button is pressed. Rotating the encoder selects the
value of XXX as C-2, C#-2, D-2… etc. all the way to …A7, A#7, B7, C8.
Edit Menu Page 3 – Button Type
This page is the same as the corresponding option for CC Numbers (see the previous section), only there
is no Step option possible for Note On/Off messages.
Explanation of button types
Normal
The Note On data will be sent out as a MIDI message on depression of the button. There will be no action
on r
elease of the button. (Not nor
mally advisable as this means the note will sustain indefinitely.)
Momentary
The Note On data will be sent out as a MIDI message on depr
ession of the button and the Note Off sent
on release.
T
oggle
When the button is pressed for the first time the Note On data is sent. The next press causes the Note Off
data to be sent. The next press causes the Note On data to be sent and so on.
Note Value:
XXX
