Display of Sustain Pedal
If a Sustain pedal is connected to the Xio’s rear panel input and activated during PLAY mode, the display
will show:
XXX shows ‘On’ if the MIDI value sent is 64 or ‘Off’, if the MIDI value sent is less than 64.
Editing a Template
This mode is used to either edit individual controls within one of the 16 onboard MIDI Templates or change the
common Template parameters (the settings across all Templates) such as the velocity curve that the keyboard
is set to. The two different EDIT Mode menus are accessed by either the first or second press of the EDIT button.
Pressing the EDIT button once, whereby the LED to the left of the button will illuminate constantly, activates the
individual Template Edit menu. Pressing the EDIT button twice, making the LED to the left of the button flash,
accesses the Common Template Edit menu.
To view all the Template controls simultaneously and edit them quickly and easily on your computer, use
the separate Template Editor application, which can be downloaded for free from www.novationmusic.com.
Sustain Pedal
XXX CC64
