NSK MEGATORQUE MOTOR SYSTEM User Manual

3. Operation
— 3-6 —
3.4.2. Monitoring State of the CC-Link Interface: Monitor BS
 Monitor BS reports the current state of the CC-Link Interface.
◊ Input as “BS/RP”.
Input the BS
key to stop real-time readout.
Fig. 3-4: Readout example of Monitor BS
State of the bus
#BS/RP
BS
FEDCBA9876543210
0000000000000000
_
Guide
0: OFF
1: ON
Table 3-3: Readout of the Monitor BS
Guide F E D C B A 9 8 7 6 5 4 3 2 1 0
Monitoring Item
Error in change of setting station number Error in change of Baud rate switicing error Error in checking of error occurrence Baud rate SW error Error on interface cheking Error in CPU CPU STOP error
Error in number of RY data Error in time over setting.
Error in time over Error in maker code Error in setting of machine code + version setting Busy communicating Error in number of slave station Error in baud rate setting Error in station number setting
