NSK MEGATORQUE MOTOR SYSTEM User Manual

3. Operation
— 3-10 —
3.5.2. Function of Control Outputs
 You can set the function of control outputs and the In-position stability timer. You may change
the preset input port function to other function , or to switch to one of expanded functions.
◊ You may assign the same fucntion to multiple ports.
◊ If you require a function other than the shipping set, you may switch a preset function to a
required one. For example, you may increase the number of idle ports by combining the Output
DRDY and WRN into the Output NRM, or the Output OTPA and OTMA into the Output
OTXA, to increase the number of idle ports.
Table 3-6: Remote output ports and assigned function
m: A register number derived from the top station number
Output
Port
code
Signal
code
Signal name Function Logic in the CN6
RXm0 PO0 DRDY
Driver Unit ready
Reports that the Motor is ready to
rotate (Those pins are open when the
Motor is not ready, or an alarm
occurs)
0: Alarm
1: Normal
RXm1 PO1 WRN
Warning
Reports abnormality in the system
0: Normal
1: Warning
RXm2 PO2 OTPA
Over travel limit
(+ direction) detected
Reports detection of over travel
(software and hardware ) in the plus
direction
0: Normal
1: Over travel limit detected (+ direction)
RXm3 PO3 OTMA
Over travel limit
(- directoin) detected
Reports detection of over travel
(software and hardware) in the
minus direction
0: Normal
1: Over travel limit detected (- direction)
RXm4 PO4 SVST
Servo state Reports the state of servo
0: Servo OFF
1: Servo ON
RXm5 PO5 BUSY
In-operation
Reports the state of positioning
operation
0: Idle
1: In operation
RXm6 PO6 IPOS
In-position
Reports the condition of positioning
error and the positioning opeation
0: Imperfect positioning or Loss of the
targetpositon
1: In-position and holding the target
position
RXm7 PO7 NEARA
Target proximity A
Reports that the Motor is
approaching to the destination
0: Not ditected
1: Proximity to the target position
！
Caution: Please follow the instruction manual for custum made products with special
Inputs/Outputs signals.
• The table above shows the shipping set.
