3. Operation
— 3-11 —
Table 3-7: Function of extended output
Output
Port
code
Signal
code
Signal name Function Logic in the CN6
‒ ‒ NEARB
Target proximity B
Reports that the Motor is
approaching to the destination
0: Not in the proximity
1: The Motor is nearing to the
target position
‒ ‒ ZONEA
Zone A
‒ ‒ ZONEB
Zone B
‒ ‒ ZONEC
Zone C
Reports the Motor has entered in a
preset zone
0: Not active
1: The limit is activated
‒ ‒ TEU
Position error, under
0: Not active
1: The error is equal or under the
threshold
‒ ‒ TEO
Position error, over
Reports the position error
0: Not active
1: The error is equal or under the
thereshold
‒ ‒ TVU
Velocity error, under
0: Out of the limit
1: The error is equal or under the
threshold
‒ ‒ TVO
Velocity error, over
Reports the velocity error
0: Out of the limit
1: The error is equal or under the
threshold
‒ ‒ TTU
Torque command, under
0: Out of the limit
1: The command is equal or under
the threshold
‒ ‒ TTO
Torque command, over
Reports the state of torque output
command
0: Out of the limit
1: The command is equal or over
the threshold
‒ ‒ TJU
Thermal loading, under
0: Out of the limit.
1: The thermal loading is equal or
under the threshold
‒ ‒ TJO
Thermal loading, over
Reports the state of thermal loading
0: Out of the limit.
1: The thermal loading is equal or
over the threshold
‒ ‒ OTXA
Travel limit switch,
± direction
Reports the detection of limit
switch (software and hardware)
in + or – direction
0: Out of the limit
1: The limit activated
‒ ‒ NRM
Normal
Reports the detection of alarm or
warning
0: Alarm or warning
1: Normal
‒ ‒ HOME
Home Return completed
Reports that the Motor has
completed the Home Return
and is on the Home position
0: Home Return is not completed,
or the commanded position is not
the Home position
1: Home Return is completed and
the commanded position is the
Home position
‒ ‒ HCMP
Home position defined
Reports that the Home position
has been defined
0: The home position is not
defined
1: The Home position is defined
To Next Page
