NTI ENVIROMUX Series Instruction Manual

NTI ENVIROMUX TEMPERATURE/HUMIDITY SENSOR ATTACHMENT
2
E-STHS-LCDW
The E-STHS-LCDW is a Temperature and Humidity sensor built into a large wall-mount LCD display with 2” character height for
easy viewing from a distance. There are two key-hole slots on the back, 4-1/2” apart, for hanging the sensor on the wall. A
template has been provided to make placement and hardware location easy. There are also two brackets (with screws) that can
be mounted to the sides. These are provided for an alternate method of mounting.
Frontview of E-STHS-LCDW
(Shown without side mounting brackets)
Rearview of E-STHS-LCDW
2” Hi
g
h

NTI ENVIROMUX Series Specifications

General

Product Type	Environmental Monitoring System
Temperature Range	-40°C to 85°C
Power Supply	12V DC or 24V AC
Network Interface	Ethernet 10/100 Mbps
Alarm Notifications	Email, SNMP
Sensor Types Supported	Temperature, Humidity, Water, Airflow
Power	12V DC or 24V AC
Operating Temperature	-40°C to 85°C
Mounting	Wall or Rack Mount
Communication Interfaces	Ethernet
Data Logging	Yes
Compliance	CE, RoHS
