Numatic TTV 678 - Machine Set-Up

22
Machine Set-Up
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF
BEFORE MAKING ANY ADJUSTMENTS
! !
Fitting the Floor-tool
To t the side pod skirts, rst remove the steel retaining strip already tted to the pod (Fig.7).
Align the steel retaining strip within the locating grooves of the rubber skirt and ret using existing screws (Fig.8)
Periodically the side skirts should be examined and checked for wear and damage. Replace as shown above.
Lower the oor-tool arm by moving the release lever to the upper position (Fig.9).
Push oor-tool onto the holder and secure with the easy-t securing pin (Fig.10).
Push waste collection pipe onto the oor-tool; ensure a tight t (Fig.11).
Note: Raise oor-tool again before driving to the cleaning area (Fig.12).
!
7
8
9
10
11
12
