Machine Operation
Breakaway Floor-tool
Ret vacuum hose to the Floor-tool when nished.
The vacuum hose has a U-bend clip which creates a U-bend in the hose preventing water spillage when the vacuum
is switched off. If you need to remove the U-bend clip for any reason always ensure it is retted correctly before you
resume operation.
Fitting the Hose Guide
Note:
DO NOT push the vacuum hose onto the Floor-tool with the Floor-tool in the raised position.
The oor-tool design incorporates a safety
knock-off feature.
Allowing it to safely disengage from its mounting
should it become caught on an obstruction, during
forward machine movement.
To re-attach the oor-tool blade to its holder.
First loosen the retaining knobs on the oor-tool body
and slide onto the holding bracket.
Tighten retaining knobs to nger tight. (See Fig.13).
