nVent RAYCHEM Elexant 4010i/4020i User Manual
RAYCHEM-AR-H60624-40X0iOpsManual-EN-1905 nVent.com
|
19
Figure 19 – Elexant 4020i Single Phase Two Pole - Connections to SSRs
L3
L2
L1
N
3PH
TB2
Circuit
Breaker
SSR
SSR
SSR
L2
L1
L3
N
8
9
To Load
Figure 20 – Elexant 4020i Three Phase - Connections to SSRs
