nVent RAYCHEM Elexant 4010i/4020i User Manual
RAYCHEM-AR-H60624-40X0iOpsManual-EN-1905 nVent.com | 22
2.6.18 Contactor Output
Note that this is a wet
contact, and provides an output voltage derived from the incoming module power. The load contactor is
placed in line with the load connections.
Note:

Figure 25 – Elexant 4020i Single Phase - Contactor Output Connections
Figure 26 – Elexant 4020i Three Phase - Contactor Output Connections
