nVent RAYCHEM Elexant 4010i/4020i User Manual
RAYCHEM-AR-H60624-40X0iOpsManual-EN-1905 nVent.com | 97
Conguration
Page Description
Default Prole Process Prole Ambient Prole
Default
State
Default
Setpoint
/Value
Default State Default
Setpoint
/Value
Default
State
Default
Setpoint
/Value
Temperature
Sensor (x)
TS2 High Temp Alarm
D,NL 100 D,NL 100 D,NL 80
TS2 High Temp Filter
0 0 300
TS2 Low Temp Alarm
D,NL 5 D,NL 5 D,NL -40
TS2 Low Temp Filter
0 0 300
TS2 Failure
D,L D,L D,L
TS3 Type
None None None
TS3 Mode
Monitor Monitor Monitor
TS3 High Temp Alarm
D,NL 100 D,NL 100 D,NL 80
TS3 High Temp Filter
0 0 300
TS3 Low Temp Alarm
D,NL 5 D,NL 5 D,NL -40
TS3 Low Temp Filter
0 0 0 0 300
TS3 Failure
D,L D,L D,L
Temp
Limiting
TS1 Use for High/
Low Temp
D D D
TS2 Use for High/
Low Temp
D D D
TS3 Use for High/
Low Temp
D D D
High Limit Alarm E,NL 700 E,NL 700 E,NL 200
Low Limit Alarm E,NL -70 E,NL -70 E,NL -70
 3 3 3
Electrical
Page
Trace Current
Current Turns Ratio 1 1 1
High Alarm D,L 30 D,L 30 D,L 30
High Alarm Filter 0 0 0
Low Alarm E,L 1 E,L 1 E,L 1
Low Alarm Filter 0 0 0
Ground Fault
Ground Fault Ratio 1 1 1
Offset 0 0 0
High Alarm E,L 20 E,L 20 E,L 20
High Alarm Filter 0 0 0
Trip Alarm E,L 30 E,L 30 E,L 30
Trace Voltage
Voltage Turns Ratio 1 1 1
High Alarm D,NL 300 D,NL 300 D,NL 300
High Alarm Filter 0 0 0
Low Alarm E,NL 90 E,NL 90 E,NL 90
Low Alarm Filter 0 0 0
Trace Resistance
Nominal 6 6 6
High Alarm D,NL 50 D,NL 50 D,NL 50
High Alarm Filter 0 0 0
Low Alarm D,NL 50 D,NL D D,NL 50
Low Alarm Filter 0 0 0
Maintenance Device Reset D D D
