nVent.com | 13
The following tables summarize model codes for the RAYCHEM T2000 series products. Note
that the first table identifies the most recent products. These components should be specified
for new designs.
Current Product Model Codes
Model Code Model Description Detailed Description
CM 2000+ RAYCHEM T2000 Control
Module with advanced
feature set
Plug-in control module, with firmware
versions V3.14 and up, that provides all heat
tracing control and monitoring functions.
Plugs into all types of CR 2000 card racks and
interfaces with all types of CT 2000 and AC
2000 modules.
AC 2000+ Alarm/Communications
Inter-face Card with GCC
functionality
Plug-in modules that provides RS-232, RS-485
or Ethernet interfacing between CM 2000/
CM 2000+ control modules and a PC or an
external upstream programming device.
Includes two relay output devices for remote
alarm and warn-ing indication.
CR 2000+ Isolated Power Card Rack
supporting AC 2000+
features
Panel mount rack provides mechanical
protection and electrical connections for the
CM 2000/CM 2000+ control modules as well
as the AC 2000+ module. All control modules
are individually powered.
CR 2000-
CPS+
Card Rack with Common
Power Supply supporting AC
2000+ features
Panel mount rack provides mechanical
protection and electrical connections for the
CM 2000/CM 2000+ control modules as well
as the AC 2000+ module. All control modules
utilize a common power source.
CT 2000 CT module for use with
Electromechanical
Contractors
Current transformer and switching module.
Load current conductors pass through to
provide accurate load current and ground
fault current measurements. Internal relay
switches an exter-nal contactor. Interfaces
with the CM 2000/CM 2000+ control
modules.
CT 2000-HAZ CT Module for use with
Solidstate Relay Modules
Approved For Hazardous
Areas
Current transformer module. Load current
conductors pass through this module to
provide accurate load current and ground
fault measurements. Internal circuitry drives
an external solid-state relay. Interfaces with
the CM 2000/CM 2000+ control modules.
BC 2000 Blank Cover Blank cover plate to occupy empty or unused
slots in all types of CR 2000 card racks.
