nvent RAYCHEM T2000 User Manual

nVent.com | 77
APPENDIX F 100 W PLATINUM RTD TABLE
DIN 43760—100 W Platinum Resistance Temperature (RTD)—0.00385 Ohms/Ohm/°C
Ohms °F °C Ohms °F °C Ohms °F °C
60.25 –148 –100 159.18 311 155 250.48 770 410
62.28 –139 –95 161.04 320 160 252.19 779 415
64.30 –130 –90 162.90 329 165 253.90 788 420
66.31 –121 –85 164.76 338 170 255.61 797 425
68.33 –112 –80 166.61 347 175 257.32 806 430
70.33 –103 –75 168.46 356 180 259.02 815 435
72.33 –94 –70 170.31 365 185 260.72 824 440
74.33 –85 –65 172.16 374 190 262.42 833 445
76.33 –76 –60 174.00 383 195 264.11 842 450
78.32 –67 –55 175.84 392 200 265.80 851 455
80.31 –58 –50 177.68 401 205 267.49 860 460
82.33 –49 –45 179.51 410 210 269.18 869 465
84.27 –40 –40 181.34 419 215 270.86 878 470
86.25 –31 –35 183.17 428 220 272.54 887 475
88.22 –22 –30 184.99 437 225 274.22 896 480
90.16 –13 –25 186.82 446 230 275.89 905 485
92.16 –4 –20 188.63 455 235 277.56 914 490
94.12 5 –15 190.45 464 240 279.23 923 495
96.09 14 –10 192.26 473 245 280.90 932 500
98.04 23 –5 194.07 482 250 282.56 941 505
100.00 32 0 195.88 491 255 284.22 950 510
101.95 41 5 197.69 500 260 285.87 959 515
103.90 50 10 199.49 509 265 287.53 968 520
105.85 59 15 201.29 518 270 289.18 977 525
107.79 68 20 203.08 527 275 290.83 986 530
109.73 77 25 204.88 536 280 292.47 995 535
111.67 86 30 206.67 545 285 294.11 1004 540
113.61 95 35 208.45 554 290 295.75 1013 545
115.54 104 40 210.24 563 295 297.39 1022 550
117.47 113 45 212.02 572 300 299.02 1031 555
119.40 122 50 213.80 581 305 300.65 1040 560
121.32 131 55 215.57 590 310 302.28 1049 565
123.24 140 60 217.35 599 315 303.91 1058 570
125.16 149 65 219.12 608 320 305.53 1067 575
127.07 158 70 220.88 617 325 307.15 1076 580
128.98 167 75 222.65 626 330 308.76 1085 585
130.89 176 80 224.41 635 335 310.38 1094 590
132.80 185 85 226.17 644 340 311.99 1103 595
134.70 194 90 227.92 653 345 313.59 1112 600
136.60 203 95 229.67 662 350 315.20 1121 605
138.50 212 100 231.42 671 355 316.80 1130 610
140.39 221 105 233.17 680 360 318.40 1139 615
142.29 230 110 234.91 689 365 319.99 1148 620
144.17 239 115 236.65 698 370 321.59 1157 625
146.06 248 120 238.39 707 375 323.18 1166 630
147.94 257 125 240.13 716 380 324.76 1175 635
149.82 266 130 241.86 725 385 326.35 1184 640
151.70 275 135 243.59 734 390 327.93 1193 645
153.58 284 140 245.31 743 395 329.51 1202 650
155.45 293 145 247.04 752 400 331.08 1211 655
157.31 302 150 248.76 761 405 332.66 1220 660
