Configuration Parameters
Parameter Factory User
HTC Tag TAG-(factory ID)
Switch Control Mode Deadband
Contactor Deadband 5°F (3°C)
HTC Console Units °F
Switch Rating 50.0 A
C.B. Current 50.0 A
Maximum Power 12000 W
TS Control Mode TS 1- Fail Off
ATC Master No
Voltage Turns Ratio 1.00 to 1
Current Turns Ratio 1.00 to 1
Auto-Cycle Enable
Auto-Cycle Interval 8
Auto-Cycle Units Hours
Load Shedding Disable
Fail Safe Mode Enable
Load Shedding Input 1 Enable
Load Shedding Input 2 Enable
Load Shedding Input 3 Enable
Load Shedding Input 4 Enable
G.2 CM 2000+ CONTROL MODULE V3.1X CONFIGURATION SHEET
= Most commonly changed setting
IMPORTANT: It is recommended that the HTC console units be selected before any other
settings are entered.
Temperature Configuration Parameters
Parameter Factory User
Setpoint Temp 70°F (21.1°C)
High TS 1 Temp Disable
High TS 1 Temp *n/a (100°F (37.7°C))
Low TS 1 Temp Enable
Low TS 1 Temp 40°F (4.4°C)
TS 1 Failure Enable
High TS 2 Temp Disable
High TS 2 Temp *n/a (100°F (37.7°C))
Low TS 2 Temp Disable
Low TS 2 Temp *n/a
(40°F(4.4°C))
TS 2 Failure Disable
Control TS Failure Enable
Temp Alarm Mode Non-Latching
Alarm Configuration Parameters
Parameter Factory User
High Load Current Disable
High Load Current *n/a (30.0 A)
Low Load Current Enable
