nvent RAYCHEM T2000 User Manual

nVent.com | 73
APPENDIX C LABEL DETAILS
STATUS
ALARM / COMMUNICATIONS
CONTROLLER
AC 2000+
ALARMS
WARNINGS
A
L
TR
TR
TR
LAN
REMOTE
LOCAL
HTC
LOCAL
PORT
RS232
DCE
RECEIVE
TRACER
2000
ALARM COMMUNICATIONS INTERFACE
AC 2000
CARRIER
TRANSMIT
REQ TO SEND
ALARM
Receiving Information
from Programmer
Carrier Detect
Transmitting Information
to Programmer
Request To Send
Active Alarm
AC 2000 ALARM CARD
AC 2000+ ALARM
COMMUNICATIONS CONTROLLER
Transmitting Data on REMOTE Port
Receiving Data on REMOTE Port
Receiving Data on LOCAL Port
Transmitting Data on LOCAL Port
LAN Link on REMOTE Port
LAN Activity on REMOTE Port
Transmitting Data on HTC Port
Receiving Data on HTC Port
Active WARNINGS
Active ALARMS
Mode STATUS
CURRENT SETPT
OUTPUT
ALARM
RECEIVE
TRANSMIT
ADDRESS
CM 2000+
F
C
CONTROL MODULE
TEMP
CM 2000/CM 2000+ Controller Card
Three digit display used to
indicate Actual Temp. ,
Load Current or Setpoint
Temp.
Actual Temp.
being displayed
Load Current
being displayed
Output On
Receiving Information
Degrees F or C for
displayed temp. value
Active Alarm
Transmitting Information
Heat Trace Module
Identification number
Setpoint being displayed
D794-009
T2000
T2000
