APPENDIX G FACTORY DEFAULT / CONFIGURATION SHEETS
G.1 CM 2000 CONTROL MODULE V2.35 CONFIGURATION SHEET
= Most commonly changed setting
IMPORTANT: It is recommended that the HTC console units be selected before any other
settings are entered.
Temperature Configuration Parameters
Parameter Factory User
Setpoint Temp 68°F (20.0°C)
High TS 1 Temp Enable
High TS 1 Temp 212°F (100.0°C)
Low TS 1 Temp Enable
Low TS 1 Temp 14°F (–10.0°C)
TS 1 Failure Enable
High TS 2 Temp Disable
High TS 2 Temp *n/a
(212°F (100.0°C))
Low TS 2 Temp Disable
Low TS 2 Temp *n/a
(14°F (–10.0°C))
TS 2 Failure Disable
Control TS Failure Enable
Temp Alarm Mode Latching
Alarm Configuration Parameters
Parameter Factory User
High Load Current Disable
High Load Current *n/a (30.0 A)
Low Load Current Enable
Low Load Current 1.0 A
High GF Current Enable
High GF Current 50 mA
GF Trip Current Enable
GF Trip Current 75 mA
High Voltage Enable
High Voltage 270 V
Low Voltage Enable
Low Voltage 90 V
Overcurrent Trip Enable
Switch Failure Enable
HTC Reset Disable
C.B. Limiting Disable
Power Limiting Disable
Switch Limiting Disable
EEROM Data Failure Disable
Alarm Output N.O.
Flash Alarm Output No
