Low Load Current 0.3 A
Alarm Configuration Parameters
High GF Current Enable
High GF Current 20 mA
GF Trip Current Enable
GF Trip Current 30 mA
High Voltage Disable
High Voltage *n/a (270 V)
Low Voltage Disable
Low Voltage *n/a (90 V)
Overcurrent Trip Enable
Switch Failure Enable
HTC Reset Disable
C.B. Limiting Disable
Power Limiting Disable
Switch Limiting Disable
Contactor Count *n/a (200,000)
EEROM Data Failure Enable
Alarm Output N.O.
Flash Alarm Output No
Configuration Parameters
Parameter Factory User
HTC Tag TAG-(factory ID)
Switch Control Mode Deadband
Contactor Deadband 5°F(3°C)
Proportional Deadband *n/a 4°F (2°C)
Cycle Time *n/a (10 min)
HTC Console Units °F
Switch Rating 60.0 A
C.B. Current 60.0 A
Maximum Power 14400 W
TS Control Mode TS 1- Fail Off
ATC Master No
Voltage Turns Ratio 1.00 to 1
Current Turns Ratio 1.00 to 1
Auto-Cycle Enable
Auto-Cycle Interval 24
Auto-Cycle Units Hours
Load Shedding Disable
Fail Safe Mode Enable
Load Shedding Input 1 Enable
Load Shedding Input 2 Enable
Load Shedding Input 3 Enable
Load Shedding Input 4 Enable
*n/a: Parameter may only appear if certain features are enabled. Values shown in brackets are the
Factory defaults if the settings are enabled.
This information defines the default CM 2000+ control module configuration as set by the factory for
firmware V3.1X. These settings are subject to change without notice.
It is the user’s responsibility to verify that all configuration parameters are chosen appropriately for
the intended application.
