NVIDIA Spectrum-2 SN3000 1U and 2U Switch Systems Hardware User Manual 127
To verify the LED status, run:
To deactivate the UID LED on a switch system, run:
Port LEDs
SN3700/SN3700C/SN3750-SX Port LEDs
Each QSFP module can be used as one 4X port/two 2X ports/four 1X ports. Each QSFP
has one dedicated bi-color LED. In order to provide link information for more than one
port by using one LED, LED splitting control button is available. You may use the button to
select between 5 indication states. By pressing on the button, the next indication state
will be selected in a cyclic manner. The current state can be identied by the LED splitting
state indication LEDs. The states and their indications are detailed in the below table.
switch (config) # led MGMT uid on
switch (config) # show leds
Module LED Status
-----------------------------------------------------------------
---------
MGMT UID Blues
switch (config) # led MGMT uid off
