2. Mount both of the outer rails (C+D) into the rack (as illustrated below), and use 8
standard pan-head screws (F) to x them to the rack. Do not tighten the screws yet.
Mounting the Outer Rails into the Rack
3. If cable accommodation is required, disassemble any of the inner rails from the
brackets attached to them, by removing and scraping the connecting screws.
Disassembling the Inner Rails for Cable Accommodation
