Configuration—Motherboard
MPC5777C EVB User Guide, Rev. 1
12 NXP Semiconductors
Signal
TP name
Shape
Description
1.25V_SR
JP2
Pin
1.25V_SR reference
1.25V_SR
JP3
Pin
1.25V_SR reference
1.25V_SR
JP4
Pin
1.25V_SR reference
3.3V_SR
JP5
Pin
3.3V_SR reference
3.3V_SR
JP6
Pin
3.3V_SR reference
3.3V_SR
JP7
Pin
3.3V_SR reference
3.3V_SR
JP8
Pin
3.3V_SR reference
5V_SR
JP9
Pin
5V_SR reference
5V_SR
JP10
Pin
5V_SR reference
5V_SR
JP11
Pin
5V_SR reference
5V_SR
JP12
Pin
5V_SR reference
GND
JP13
Pin
Ground reference
GND
JP14
Pin
Ground reference
GND
JP15
Pin
Ground reference
GND
JP16
Pin
Ground reference
5V_SR
TP15
Hook
5V_SR reference
5V_LR
TP14
Hook
5V_LR reference
3.3V_SR
TP16
Hook
3.3V_SR reference
1.25V_SR
TP17
Hook
1.25V_SR reference
FRA-INH2
TP5
Pad
Unused
FRA-INH1
TP1
Pad
Unused
FRA-ERRN
TP2
Pad
Unused
FRA-RXEN
TP6
Pad
Unused
FRB-INH2
TP7
Pad
Unused
