7. Default Jumper Summary Table
The following table details the DEFAULT jumper configuration of the EVB as set up on delivery.
7.1 Default Jumper Table - Motherboard
On delivery the motherboard comes with a default jumper configuration. Table 26 lists and describes
briefly the jumpers on the MPC57xx motherboard and indicates which jumpers are on/off on delivery
of the board.
Table 262: Default Jumper Table-Motherboard
Jumper
Default
PCB Legend
Description
J8
On
MASTER
LIN Master/Slave select
J9
On
CAP A DIS
Disable capacitor circuitry for FlexRAY_A signals
J10
On
CAP A DIS
Disable capacitor circuitry for FlexRAY_A signals
J11
On
CAP B DIS
Disable capacitor circuitry for FlexRAY_B signals
J12
On
CAP B DIS
Disable capacitor circuitry for FlexRAY_B signals
J13
On
SCI TX
1-2: Connect SCI TX signal
J14
On
SCI RX
1-2: Connect SCI RX signal
J15
On
LIN_EN
1-2: Enable LIN PHY U50
J16
On
LIN_RX
1-2: Connect LIN RX signal
J17
On
LIN_TX
1-2: Connect LIN TX signal
J18
On
—
1-2: Ethernet signal: RXCLK
J20
On
—
Ethernet signal: CRS_LEDCFG
J21
On
CAN2_EN
PHY U2 configuration:
1-2: WAKE to GND
3-4: STB to 5V
5-6: EN to 5V
J22
On
—
Ethernet PHY power-on
J23
On
CAN-EN
PHY U1 configuration:
1-2: WAKE to GND
3-4: STB to 5V
5-6: EN to 5V
J24
On
—
1-2: Ethernet signal: RXER_MDIXEN
J25
On
SCI-PWR
1-2: SCI PHY power-on
J26
On
—
1-2: Ethernet signal: RXDV_MIIMODE
J27
On
FR-A
1-2: PHY U4 TX to MCU
3-4: PHY U4 TXEN to MCU
5-6: PHY U4 RX to MCU
