NXP Semiconductors MPC5777C User Manual

Board Interface Connector
MPC5777C EVB User Guide, Rev. 1
23 NXP Semiconductors
23
GND
24
GND
25
MDO5
26
Test Point
27
MDO6
28
Test Point
29
GND
30
GND
31
MDO7
32
Test Point
33
MDO8
34
Test Point
35
GND
36
GND
37
MDO9
38
Test Point
39
MDO10
40
Test Point
41
GND
42
GND
43
MDO11
44
MDO13
45
MDO12
46
MDO14
47
GND
48
GND
49
MDO15
50
NC
S1
GND
S2
GND
4.6 USB/UART Transceiver
USB to UART transceiver interface provided on the daughter card. USB TYPE B connector interfaced
with FT232RQ, USB to serial UART chip (U502).
The USB to serial UART connection is shown in Figure 17.
Figure 17: USB/UART Transceiver Circuit
4.7 Ethernet (FEC) Interface
The signals from the MCU’s Fast Ethernet Controller are terminated to Mother Board interface
connector, J501. Further these signals are connected with Ethernet Physical Interface in the Mother
Board. Also, in order to support Reduced Media-Independent Interface (RMII) mode, the Daughter
