NXP Semiconductors MPC5777C - Page 40

Board Interface Connector
MPC5777C EVB User Guide, Rev. 1
40 NXP Semiconductors
Table 28: Test points — 516 daughter card
Signal
TP name
Shape
Description
MB PL11
TP3
Pad
Motherboard connection PL11
MB PL13
TP4
Pad
Motherboard connection PL13
MB PL15
TP5
Pad
Motherboard connection PL15
MB PJ5
TP6
Pad
Motherboard connection PJ 5
MB PL9
TP7
Pad
Motherboard connection PL 9
MB PF13
TP8
Pad
Motherboard connection PF13
MB PJ7
TP9
Pad
Motherboard connection PJ7
MB PD7
TP10
Pad
Motherboard connection PD 7
MB PD6
TP11
Pad
Motherboard connection PD6
CE2
TP12
Hook
Chip enable 2 input of SRAM (U502)
ADSC
TP13
Hook
Address strobe from MCU to SRAM
5V_LR
TP14
Hook
5V linear regulator
ZZ
TP15
Hook
Sleep input of SRAM
RST_OUT_B
TP16
Pad
Reset out of U4
J23 26
TP17
Pad
NEXUS connection J23 26
J23 28
TP18
Pad
NEXUS connection J23 28
J23 32
TP19
Pad
NEXUS connection J23 32
J23 34
TP20
Pad
NEXUS connection J23 34
J23 38
TP21
Pad
NEXUS connection J23 38
J23 40
TP22
Pad
NEXUS connection J23 40
J30 8
TP23
Pad
JTAG connector J30 8
U5 8
TP24
Pad
IC U5 PIN 8
MB PA8
TP25
Pad
Motherboard connection PA8
MB PA14
TP26
Pad
Motherboard connection PA14
MB PA6
TP27
Pad
Motherboard connection PA6
MB PA5
TP28
Pad
Motherboard connection PA5
MB PA7
TP29
Pad
Motherboard connection PA7
MB PA9
TP30
Pad
Motherboard connection PA9
SBC_5V
TP31
Pad
SBC_5V
GND
GT1 to GT11
Hook
Ground Reference
5.0V_SR
JP1
Pin
5.0V Switching Regulator
GND
JP2
Pin
Ground Reference
3.3V_SR
JP4
Pin
3.3V Switching Regulator
5.0V_SR
JP5
Pin
5.0V Switching Regulator
1.25V_SR
JP6
Pin
1.25V Switching Regulator
GND
JP7
Pin
Ground Reference
3.3V_SR
JP8
Pin
3.3V Switching Regulator
