ODA OPS Series - Required Efficiency for Detailed Setting; Calibration Technique 4 4. Calibration Technique; Instrument Connection

4-3. Required efficiency for accurate calibration
Required Efficiency
Agilent 82341C
PC based Calibration
Instrument recommendatio
n
Usage
GPIB Controller
Full GPIB capabilities
g
Interface card
PC
based
Calibration
Agilent 34401A
Electronic Load Agilent 6063B
Voltage Range: 50 Vdc
Current Range: 10 Adc
Open and Short Switches
Transient On
/
Off
Current Calibration,
Power Supply Protection
Digital Voltmeter Voltage Calibration
GPIB
Controller
Full
GPIB
capabilities
Resolution: 0.1 mV
Accuracy: 0.01%
4 4 Calibration Technique
while Current Calibration
Monitoring Voltage
ripple & noise MeasuringOscilloscope
100 MHz with
20MHz bandwidth
Tektronix
TDS3014
Current
monitoring
0.01Ω , 0.01%
Transient
On/Off
4
-
4
.
C
a
lib
ra
ti
on
T
ec
h
n
iq
u
e
Technical description about calibration below :
Instrument Connection
▌Connect output terminal and measuring instrument as below.
▌While Voltage Calibration, Switch OFF electric load, or remove from output terminal.
▌g , , p
< Diagram 4-1 >
