ODES UTV Desertcross 1000cc-3 - PTO COVER OIL SEAL

3. ENGINE
3-
81
1. Bearing cover
2. O-ring
4. Install drive shaft oil seal using the fo1lowing
tool.
1. Bearing cover
2. Oil seal
3. Oil seal installer
REQUIED
ERIVE SHAFT OIL
SEAL
5. Install O-ring in rear bearing cover.
1. O-ring
2. Bearing cover
6. Reinstall remaining parts in the reverse order of
removal.
PTO COVER OIL SEAL
To replace oil seal it is not necessary to remove
engine from vehicle.
PTO Oil Seal Removal
Refer to CONTINUOUSLY VARLABLE
TRAINSMISSION (CVT) subsection to remove
the following parts:
- CVT cover
- Drive pulley
- Driven pulley
- CVT air guide.
Remove oil seal with a small flat screwdriver.
NOTICE Avoid scoring surfaces with tool.
1. PTO cover
2. Oil seal
PTO Oil Seal Inspection
Check oil seal running surface of crankshaft PT0
side for grooves. Replace if necessary.
