10. ELECTRICAL SYSTEM
10-
exterior lighting system
Removal and Installation of Front Combined Headlamps
1、Remove the positive and negative connection of battery。
2、Open front hood。
3、Remove （1 bolt , 2 bolt , 3 headlamp bracket , 4 headlamp;）
4、install vice versa
pay attention to：
1、 Halogen bulbs produce a lot of heat when used, if the surface of the bulb is dirty, heat will
continue to accumulate to shorten the service life of the bulb, when changing the bulb to
hold the metal flange rather than glass. The ohmmeter can be used to detect the
resistance of the bulb, the resistance is infinite or 0 to replace the bulb or lamp
combination;
2、 Front position lamp and front turn lamp are LED lamp band structure, can use ohmmeter to
detect bulb resistance, resistance infinity or 0 replacement lamp combination
Removal and installation of light control switches
1、Remove the positive and negative connection of battery。
2、Open hood cover。
3、Disconnect headlight switch connector。
4、Push the switch out of the back of the meter。
5、Check the conductivity between the ignition switch
Terminals with an ohmmeter and replace the switch
if it does not meet the technical requirements
Removal and installation of steering light control switches
1、Open hood cover。
2、Disconnect steering light or four-flash switch connector。
3、Push the switch out of the back of the meter。
4、Check the conductivity between the ignition switch
terminals with an ohmmeter and replace the headlamp
if it does not meet the technical requirements。
