ODES UTV Desertcross 1000cc-3 - Removal and Installation of Top Lamps

10. ELECTRICAL SYSTEM
10-
4
Removal and Installation of Top Lamps
1、Remove the positive and negative connection of battery。
2、Disconnect the positive power supply connected to the top lamp。
3、Disassemble (1, bolt ;2, top lamp) in the sequence shown in the diagram
4、The order of installation is contrary to the order of disassembly
Removal and Installation of Top Lamp Control Switch
1、Open hood cover。
2、 Disconnect headlamp switch connector。
3、Push the switch out of the back of the meter。
4、Check the conductivity between the ignition switch
terminals with an ohmmeter and replace the switch
if it does not meet the technical requirements。
Removal and installation of horn
1、 Disconnect horn plug。
2、Disassemble (1, bolt ;2, horn) in sequence shown in the diagram。
3、The order of installation is contrary to the order of disassembly。
Removal and installation of horn control switches
1、Open hood cover。
2、Disconnect horn switch。
3、Push the switch out of the back of the meter。
4、Check the conductivity between the ignition
switch terminals with an ohmmeter and replace
the switch if it does not meet the technical requirements。
