OEM PIZZAFORM - 5.2 Technical Characteristics

5.0
2
Electric connections
Voltage/ frequency 400 V 3N - 50Hz 230 V 3 - 50Hz
Power 6,56 kW 6,56 kW
Characteristics of the plates
Diameter 45 cm
33 cm (on request)
Upper plate flared
flat
Lower plate flat
Other useful data for working and regulation
Maximum pressure between the plates 2500 kg
Minimum Temperature of the plates 20° C
Maximum Temperature of the plates 180° C
Minimum distance to be set between the plates 0 mm
Maximum distance to be set between the plates 10 mm
Cable (H07ANF type) 5x2,5 mm
2
4x4 mm
2
5.2 TECHNICAL CHARACTERISTICS
