OES ISC-9000 - Hardware; Front Panel; Back Panel

www.oes-scoreboards.com | 1.877.652.5833
4056 Blakie Rd., London ON Canada N6L 1P7
Rev: ISC9000_j12.0_1.3
Issued: 2021-10-21
Page 5 of 44
HARDWARE
FRONT PANEL
BACK PANEL
See next page for interface details.
5.1” GRAPHIC BACKLIT LCD
GAME TIME CONTROL
- Manual Horn Button
- Time running Indicator LED
- RUN/STOP Buttons
CONFIGURABLE 4x8 KEYPAD
- Insert slides in from left
ALPHA-NUMERIC KEYPAD
- Complete with CLEAR and ENTER keys
