INTERFACE DETAILS
Power-In Module (Labeled “100-230VAC” & “1A SLO-BLO”)
IEC connector
Input: 100-230VAC, 50-60Hz
Fuse: 1A, 250V, SLO-BLO, 5x20mm
Remote Inputs (Labeled “REMOTE 1” & “REMOTE 2”)
XLR 3 pin connector
Software Configurable
Available Remote: OES # ISCREM
Controller Port (Labeled “9000 IN” & “9000 OUT”)
XLR 5 pin connector
RS485 2-Wire
Mating Connectors – OES # CN138F and CN139B
Pin out:
Pin 3 – RS+
Pin 4 – RS-
Game Port 1 (Labeled “GAME OUT”)
XLR 4 pin connector
RS485 2-wire
Mating Connector – OES # CN137D
Pin out:
Pin 3 – RS+
Pin 4 – RS-
Game Port 2 (Labeled “GAME OUT”)
DB9 Male Connector
RS232 DTE
Serial port settings: Baud Rate = 9600, Data Bits = 8, Parity = None, Stop Bits = 1 and Flow Control = None
Pin out:
Pin 2 – Data into Controller (Should not be used, for diagnostics only)
Pin 3 – Data out of Controller
Pin 5 – Ground
USB
USB B connector
Used for diagnostic and upgrades
Ethernet / WI-FI
RJ45 connector
Not shown, optional (ISC9000-IP)
OES Coax
BNC connector
Not shown, optional (ISC9000-CX)
