Adventurer Pro EN-13
21
Digital Display Window
3.1 Overview of Controls and Display Functions (Cont.)
TABLE 3.1-1 ADVENTURER PRO CONTROLS AND DISPLAY FUNCTIONS.
19 20
22
23
24
25
26
27
28
30
31
32
33
29
No. Description No. Description
1 On / Zero / Off / Yes Button 18 Lock Switch
2 Print Unit / No Button 19 Primary (7 segment) display
3 Level Bubble 20 Brackets
4 Function Mode / Back button 21 Units of Measurement
5 Tare Menu-Cal / Exit Button 22 Memory Indicator
6 Display 23 Battery Strength Indicator
7 Pan 24 Pieces Indicator
8 Type label on side of housing 25 Secondary (14 Segment) Display
9 Data label 26 Gross Indicator
10 Weigh Below Opening 27 Brutto Indicator
11 Battery Compartment 28 Tare Indicator
12 Leveling feet 29 Preset Tare Indicator
13 COM 1 Connector 30 Net Indicator
14 COM 2 Connector 31 Stability Indicator
(AV...R and AV...U Models only)
15 Wind Ring 32 Negative Indicator
16 Draft Shield 33 Center of Zero Indicator
17 Power Connector
