25
Trooper Scale
5.1 Legal for Trade (LFT) Operation and LFT Sealing
Legal for Trade (LFT) operation is possible through a LFT Lock Switch located on the PC board. The Scale must be
calibrated prior to performing this proceedure.
Procedure
Set up Scale, and calibrate. After this is done, remove
power from the Scale.
Turn the scale over in the position as shown and remove
the Lock Switch cover plate.
Refer to the illustration at the left and notice the position
of the LFT switch. To lock out the menus, slide the LFT
switch to the position shown.
Bottom of Trooper
Replace the Lock Switch cover and housing screw cover.
The two screws are cross drilled and can accept a wire
seal.
NOTICE: The Trooper Scale has been tested and found to
comply with Class lll requirements of NIST Handbook 44.
After the Scale has been tested and found to comply with
local applicable regulations by a local weights and mea-
sures official, it may be sealed as follows:
LEAD AND WIRE SEAL
See illustration atleft. Place wire seal through the holes
in the screw and ribs as shown and compress the lead
seal in place.
PAPER SEAL
If an audit trail or paper seal will be used, place a paper
seal over both access covers.
Sealing the Scale with a Lead Seal
LFT OFF
(UNLOCKED)
LFT ON
(LOCKED)
Sealing the Scale with a Paper Seal
PAPER SEALS
