B4400/4500/4550/4600 User’s Guide
13
Installation
Operation Environment
• A firm surface such as a table or desktop
• Space to open the cover, and pull out the paper tray and
the rear paper output extender
• Air circulation around the printer to prevent overheating
• A nearby power source
• Room temperature of 50° to 90° F (10° to 32° C).
• Relative Humidity of 20-80%
• No direct sunlight
Unpacking
NOTE: Save packing materials, including the black light-shield
bag for storing the image drum, in the event that you need to
repack the printer for shipment.
Check contents:
1. Printer
2. Power cord
3. Toner cartridge
4. Black light-shield bag
5. Quick Installation Guide
6. CD ROM: Printer installation/User Guide pdf
7. Safety and Warranty booklet
8. Registration card
Remove shipping tape (1), desiccant agent (2) and film (3).
1
2
3
To Next Page
