C3600n User’s Guide
128
10. Change the slide bar values of gamma, hue, brightness, and
saturation to adjust the color.
Use primary colors of ink
Select this to adjusts the settings to the standard hues
for the printer.
The Gamma slide bar adjusts total brightness.
The Hue/Brightness slide bar adjusts output color.
Use the printer color buttons to switch to a different color.
Brightness
For Brighter color, slide the Gamma bar to the left.
Hue
Adjustments are made relative to positions on the color
wheel.
Move forward = + (counter-clockwise)
Move backward = - (clockwise)
Hue Toner printing
R (Red) 50% yellow and 50%
magenta
Y (Yellow) 100% yellow
G (Green) 50% cyan and 50% yellow
C (Cyan) 100% cyan
B (Blue) 50% magenta and 50%
cyan
M (Magenta) 100% magenta
