7. Troubleshooting and repair procedure
Panel display
(The mark indicates no
message in the upper row.)
ON
LINE
lamp
Inspection
lamp
Details
Remedial
measure
%COLOR% Image
Drum Life
Varies On Indicates that the image drum has
reached end of life.
This status (warning) is issued when
the cover is Opened/Closed once
after the Image Drum Life end error
is issued to recover the printer once.
%COLOR%
Yellow
Magenta
Cyan
Black
Replace the
image drum of
the indicated
color.
Belt Reflex Error
Varies On Belt reflectance check error
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when the
PU firmware has detected this status,
this error does not occur in the user
environment.
−
Density Shutter Error2
Varies Varies Density correction shutter error 2
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when the
PU firmware has detected this status,
this error does not occur in the user
environment.
−
Density Shutter Error1
Varies Varies Density correction shutter error 1
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when the
PU firmware has detected this status,
this error does not occur in the user
environment.
−
Density Color
Calibration Error
Varies Varies Density correction color calibration
error
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when the
PU firmware has detected this status,
this error does not occur in the user
environment.
−
Density Color Sensor
Error
Varies Varies Density correction color sensor error
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when the
PU firmware has detected this status,
this error does not occur in the user
environment.
−
Panel display
(The mark indicates no
message in the upper row.)
ON
LINE
lamp
Inspection
lamp
Details
Remedial
measure
Density Black
Calibration Error
Varies Varies Density correction black calibration
error.
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when the
PU firmware has detected this status,
this error does not occur in the user
environment.
−
Density Black Sensor
Error
Varies Varies Density correction black sensor error.
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when the
PU firmware has detected this status,
this error does not occur in the user
environment.
−
%COLOR% Image
Drum Smear Error
Varies Varies Density correction ID ERROR 2.
This error occurs when abnormal
density due to the LED head focus
error is detected. (Extremely stained
LED head)
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when the
PU firmware has detected this status,
this error does not occur in the user
environment.
%COLOR%
Yellow
Magenta
Cyan
Black
−
%COLOR% Low
Density Error
Varies On Density correction ID ERROR.
This error occurs when abnormal
density is detected when stain has
occurred in print due to ID error.
(Extremely out of focus).
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when the
PU firmware has detected this status,
this error does not occur in the user
environment.
%COLOR%
Yellow
Magenta
Cyan
Black
−
