8. Connection diagrams

Unit Electrical circuit diagram, connection Part outside view Resistance value

ID up/down motor

Between pin-1 and pin-2: 6.1

Between pin-3 and pin-4: 6.1

Fuser unit motor

IP1IP2

Across both ends of IP1 and IP2: 1

or less
