Oki C834 User Manual

- 133 -
7. Maintenance
2
Insert your finger into the recess on the right side of the machine and pull the
front cover open lever (1) to open the front cover (2) forward.
3
Press the open button (3) and open the output tray (4).
4
Take all the four image drums out of the machine, and then place them on a
flat surface.
• Use extra care when handling the image drum (the green cylinder), because it is fragile.
5
Cover the image drums you took out with paper so that the image drums do
not expose to the light.
Burns may result.
The fuser unit is extremely hot. Do not touch it.

Oki C834 Specifications

General

Print Technology	LED
Maximum Paper Size	A3
Processor	800 MHz
Operating Systems Supported	Windows, Mac OS, Linux
Dimensions	449 x 552 x 360 mm
Weight	37 kg
Print Resolution	1200 x 600 dpi
Duplex Printing	Yes
Memory	1 GB
Connectivity	USB, Ethernet
Interface	USB, Ethernet
Media Size	A6 to A3
