Oki C834 User Manual

- 135 -
7. Maintenance
10
Turn the blue knobs (5) on both sides of the belt unit in the direction of the
arrow to lock the belt unit.
• Do not forget to turn the knobs and lock the belt unit. If you do not turn the knobs to lock the belt unit, image
drum cannot be attached properly.
11
Return all the four image drums to the machine.
• Use extra care when handling the image drum (the green cylinder), because it is fragile.
12
Close the output tray (4) by pushing the center of the output tray firmly.
13
Close the front cover (2).

Oki C834 Specifications

General

Print Technology	LED
Maximum Paper Size	A3
Processor	800 MHz
Operating Systems Supported	Windows, Mac OS, Linux
Dimensions	449 x 552 x 360 mm
Weight	37 kg
Print Resolution	1200 x 600 dpi
Duplex Printing	Yes
Memory	1 GB
Connectivity	USB, Ethernet
Interface	USB, Ethernet
Media Size	A6 to A3
