- 137 -
7. Maintenance
2
Insert your finger into the recess on the right side of the machine and pull the
front cover open lever (1) to open the front cover (2) forward.
3
Press the open button (3) and open the output tray (4).
4
Pull forward the left locking lever (5) of the fuser unit to unlock.
5
Hold the fuser unit handle (6) and take out the fuser unit from the machine.
Possible to get burned.
Since the fuser unit gets hot, carry out the operation carefully, and when lifting it up you
must hold it by the handle. Do not try to hold it whilst it is hot. Wait until it has cooled
down and then carry out the operation.
To Next Page
