- 115 -
Replacing Consumables and Maintenance Units
4
4. Maintenance
7 Unpack the replacement toner cartridge,
and gently shake it up and down and
side to side.
8 Remove the tape (8) from the toner
cartridge..
8
9 Insert a new toner cartridge (9) by
aligning its left side indentation (10)
with the protrusion (11) on the image
drum so the toner cartridge and image
drum color labels align. Then x the
right side rmly into place.
Note
● Do not insert a toner cartridge without removing the
tape.
10
11
➊
➋
9
10 Turn the blue lever (6) of the toner
cartridge in the direction of the arrow
fully while pressing the top of the toner
cartridge.
6
11 Close the top cover (4) by pushing the
both sides of the cover rmly.
4
12 Close the front cover (2).
2
Note
● The front cover cannot be closed if the top cover is
not closed securely.
13 Please recycle toner cartridges.
Memo
● If you must dispose of a toner cartridge, put it in a plastic
bag or similar container and dispose of it in accordance
with your municipality’s ordinances or guidelines.
